Rated Power (1 KHz, THD+N=0.1%) |
8Ω stereo 1500W |
|
4Ω stereo 2000W |
|
2Ω stereo 2500W |
|
8Ω bridge 4000W |
|
4Ω bridge 5000W |
Frequency Response (1W 8Ω stereo) |
20Hz ̴ 20KHz(±1dB) |
Mode |
Stereo/Bridge/Parallel |
Input connectors |
Jack & female XLR (Neutrik®) |
Output connectors |
Binding post & Speakon (Neutrik®) |
Input Impedance |
Balanced 20K Unbalanced 10K |
Input Sensitivity |
0.775V/1V/1.4V |
Total Harmonic Distortion (20Hz~20KHz Rated Power, 80) |
≤0.05% |
S/N ratio (8Ω, Rated Power 8Ω) |
≥90dB |
Damping Factor (1KHz, 89) |
≥800 |
Dimension (W x H x D) |
525x483x133 mm |
Net Weight |
47.5kg |
Gross Weight |
48.5Kg |
