Rated Power (1 KHz, THD+N=0.1%) |
8Ω stereo 2x1300W |
|
4Ω stereo 2x1950W |
|
2Ω stereo 2x2200W |
|
8Ω bridge 3900W |
|
4Ω bridge 4400W |
Frequency Response (1W 8Ω stereo) |
20Hz ̴ 20KHz(±1dB) |
Mode |
Stereo/Bridge/Parallel |
Input connectors |
Jack & female XLR (Neutrik®) |
Output connectors |
Binding post & Speakon (Neutrik®) |
Input Impedance |
Balanced 20K Unbalanced 10K |
Crosstalk (20Hz~20KHz Rated Power 8Ω) |
≥60dB |
Input CMRR |
≥60dB |
Output Circuitry |
Class H |
Idle Current Draw |
2.2A |
Damping Factor (1KHz, 89) |
≥500 |
Dimension (W x H x D) |
483x132x485 mm |
Gross Weight |
30.5Kg |
