Rated Power (1 KHz, THD+N=0.1%)

8Ω stereo   800W

4Ω stereo   1300W

8Ω bridge   3000W

Frequency Response (1W 8Ω stereo)

20Hz   ̴ 20KHz(±1dB)

Mode

Stereo/Bridge/Parallel

Input connectors

Jack & female XLR (Neutrik®)

Output connectors

Binding post & Speakon (Neutrik®)

Input Impedance

Balanced            20K

Unbalanced       10K

Crosstalk (20Hz~20KHz Rated Power 8Ω)

≥50dB

Input Sensitivity

0.775V/1V/1.4V

Total Harmonic Distortion        (20Hz~20KHz Rated Power, 80)

≤0.05%

S/N ratio (8Ω, Rated Power 8Ω)

≥90dB

Damping Factor (1KHz, 89)

≥500

Dimension (W x H x D)

465x483x133 mm

Net Weight

33kg

Gross Weight

34.5Kg
