Rated Power (1 KHz, THD+N=0.1%) |
8Ω stereo 2x1600W |
|
4Ω stereo 2x2600W |
|
2Ω stereo 2x4200W |
|
8Ω bridge 5200W |
|
4Ω bridge 8400W |
Frequency Response (1W 8Ω stereo) |
20Hz ̴ 20KHz |
Mode |
Stereo/Bridge/Parallel |
Input connectors |
Jack & female XLR (Neutrik®) |
Output connectors |
Binding post & Speakon (Neutrik®) |
Input Impedance |
Balanced 20K Unbalanced 10K |
Input Sensitivity |
26dB/32dB/38dB |
Channel Separation (8Ω Load, 1KHz and below) |
≥70dB |
Filter Capability |
3300µf/ 200V x 12 |
Output Circuitry |
Class AB+D |
Total Harmonic Distortion (20Hz~20KHz Rated Power, 8Ω) |
≤0.02% |
S/N ratio (8Ω, Rated Power 8Ω) |
≥95dB |
Damping Factor (1KHz, 89) |
≥800 |
Dimension (W x H x D) |
483x458x133 mm |
Gross Weight |
39Kg |
