Key features:
Rated Power (1 KHz, THD+N=0.1%) |
8Ω stereo 4x1100W |
|
4Ω stereo 4x1800W |
|
2Ω stereo 4x2100W |
|
8Ω bridge 2x3600W |
|
4Ω bridge 2x4200W |
Frequency Response (1W 8Ω stereo) |
20Hz ̴ 20KHz(±2dB) |
Mode |
Stereo/Bridge/Parallel |
Input connectors |
female XLR (Neutrik®) |
Output connectors |
Speakon (Neutrik®) |
Input Impedance |
Balanced 20K Unbalanced 10K |
Input Sensitivity |
0.775V/1V/38dB |
Slew Rate |
35V/µs |
Filter Capability |
3300µf/ 200V x 8 |
S/N ratio (8Ω, Rated Power 8Ω) |
≥95dB |
Channel Separation (8Ω load, 1KHz and below) |
≥70dB |
Damping Factor (1KHz, 89) |
≥250 |
Dimension (W x H x D) |
483x444x89 mm |
Gross Weight |
33.8Kg |
