GENERAL SPECIFICATIONS
|
Nominal Diameter |
18inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.1ohm |
|
Power Handling |
1500Watts |
|
Sensitivity |
100db |
|
Frequency Range |
32-2.0KHZ |
|
Voice-coil Diameter |
99.3mm |
|
Voice-coil Material |
PISV |
THIELE-SMALL PARAMETERS
|
Resonance Frequency |
Fs |
32Hz |
|
DC Resistance |
Rte |
5.5ohm |
|
Mechanical Factor |
Qms |
6.79 |
|
Electrical Factor |
Qes |
0.49 |
|
Total Factor |
Qts |
0.45 |
|
BL Factor |
BL |
22.9 T-m |
|
Effective Moving Mass |
Mms |
205 gr |
|
Equivalent Cas Air Load |
Vas |
199 liters |
|
Effective Piston Area |
Sd. |
1.22 m2 |
|
Half-Space Efficiency |
Eff |
1.89% |
MOUNTING INFORMATION
|
Overall Diameter |
460mm |
|
Mount Buffer Cutout Diameter |
425mm |
|
Bolt Circle Diameter |
440mm |
|
Bolt Hole Diameter |
7.0mm |
|
Overall Depth |
224mm |
|
Not Weight |
15 Kg |
