SUPER 18XS

  • 1400W RMS power
  • 35 -1.0KHz Frequency range
  • 99.3mm Voice coil
  • 96dB Sensitivity
  • Optimized magnet and FEA analyse
  • WHATSAPP CATALOG AND PRICE

SUPER 18XS

Introducing the Aeron Super 18XS, an 18-inch subwoofer driver that redefines the audio experience with its powerful performance and eye-catching design. With a striking majestic red color, this subwoofer not only delivers exceptional sound but also adds a touch of elegance to any audio setup.

Boasting a formidable 1400W power output, the Super 18XS ensures deep and thunderous bass that can shake the room. Its 4-inch voice coil is designed for optimal power handling and efficiency, allowing you to push the boundaries of your audio system. The dual silicone spider provides stability and control, ensuring precise and accurate bass reproduction.

The Super 18XS is engineered for versatility, offering a frequency response from 35Hz that captures the full spectrum of low-frequency sounds. Whether you're a music enthusiast, a home theater aficionado, or a professional audio engineer, this subwoofer driver is designed to meet the demands of every budget without compromising on quality.

Immerse yourself in a rich audio experience with the Aeron Super 18XS. Elevate your sound system to new heights with this powerful and visually stunning subwoofer driver, delivering unparalleled performance that will leave a lasting impression on any audio enthusiast.

SUPER 18XS

Nominal Diameter

18inch

Nominal Impedance

8ohm

Minimum Impedance

5.4ohm

Nominal Power Handling

1400Watts

Continuous Power Handling

2800Watts

Sensitivity

95dB

Frequency Range

35-1KHz

Voice-coil Diameter

99.3mm

Voice-coil Material

Copper

Voice-coil Winding Depth

32.5mm

Effective Diaphragm Diameter

390mm

Kind of layer

In/out

Number of layers

2

Top Plate Thickness

15

Spider

Double Silicone

Flux Density

1.15T

Magnet Diameter

220*30mm

Magnet Material

Ferrite

Magnet Grade

Y30

Magnet Gap Depth

15





Resonance Frequency

Fs

35Hz

DC Resistance

Rte

5.1ohm

Mechanical Factor

Qms

16.64

Electrical Factor

Qes

0.535

Total Factor

Qts

0.519

BL Factor

BL

24.75T-m

Effective Moving Mass

Mms

262.1gr

Equivalent Cas Air Load

Vas

157.17liter

Effective Piston Area

Sd

0.122 m

Max. Linear Excursion

Xmax

12.5mm

Half Space Efficiency

Eff

1.6%

Efficiency Bandwidth Product

EBP

66.01

Compliance Value

Cms

0.083





Overall Diameter

460mm

Buffer Cut-out Dia.

424mm

Bolt Circle Dia.

445mm

Bolt Hole Dia.

7.0mm

Gasket Thickness

16mm

Overall  Depth

239mm

Magnet Dia.

220mm

Net Weight

14.5 kg
