GENERAL SPECIFCATIONS
|
Nominal Diameter |
18inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.5ohm |
|
Nominal Power Handling |
2000Watts |
|
Continuous Power Handling |
4000Watts |
|
Sensitivity |
97.0db |
|
Frequency Range |
32-1.5KHZ |
|
Voice-coil Diameter |
125mm |
|
Voice-coil Material |
EISV |
|
Kind of layer |
in/out |
|
Magnet Diameter |
280mm |
|
Magnet Material |
Ferrite |
THIELE-SMALL PARAMETERS
|
Resonance Frequency |
Fs |
32Hz |
|
DC Resistance |
Rte |
5.5ohm |
|
Mechanical Factor |
Qms |
11.509 |
|
Electrical Factor |
Qes |
0.252 |
|
Total Factor |
Qts |
0.247 |
|
BL Factor |
BL |
33.774 T-m |
|
Effective Moving Mass |
Mms |
232.74 gr |
|
Equivalent Cas Air Load |
Vas |
179.8 litres |
|
Effective Piston Area |
Sd. |
0.12 m2 |
|
Max. Linear Excursion |
Xmax |
11mm |
|
Vibration velocity |
Cms |
0.084 |
INSTALLATION INFORMATION
|
Overall Diameter |
496/458.2mm |
|
Baffle Cut-out Diameter |
433mm |
|
Bolt Circle Diameter |
474.5*8.06.3. |
|
Gasket Thickness |
18mm |
|
Overall Depth |
207mm |
|
Not Weight |
19.7kg |
