Nominal Diameter |
18inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
4.6ohm |
|
Nominal Power Handling |
2400Watts |
|
Continuous Power Handling |
4800Watts |
|
Sensitivity |
97.8dB |
|
Frequency Range |
30-1KHz |
|
Voice-coil Diameter |
126mm |
|
Voice-coil Material |
EISV |
|
Kind of layer |
In/out |
|
Magnet Diameter |
280*20mm X2 |
|
Magnet Material |
Ferrite |
|
Resonance Frequency |
Fs |
30Hz |
|
DC Resistance |
Rte |
4.6ohm |
|
Mechanical Factor |
Qms |
8.544 |
|
Electrical Factor |
Qes |
0.305 |
|
Total Factor |
Qts |
0.294 |
|
BL Factor |
BL |
29.262T-m |
|
Effective Moving Mass |
Mms |
216.9gr |
|
Equivalent Cas Air Load |
Vas |
163.62liter |
|
Effective Piston Area |
Sd |
0.13 m |
|
Max. Linear Excursion |
Xmax |
15mm |
|
Vibration velocity |
Cms |
0.06 |
|
Overall Diameter |
487mm |
|
Baffle Cut-out Dia. |
420mm |
|
Bolt Circle Dia. |
470mm |
|
Gasket Thickness |
17mm |
|
Overall Depth |
214mm |
|
Net Weight |
24.8kg |
