Nominal Diameter |
18inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
4.6ohm |
|
Nominal Power Handling |
1600Watts |
|
Continuous Power Handling |
3200Watts |
|
Sensitivity |
98dB |
|
Frequency Range |
30-1KHz |
|
Voice-coil Diameter |
100mm |
|
Voice-coil Material |
EISV |
|
Kind of layer |
In/out |
|
Magnet Diameter |
220*18mm X2 |
|
Magnet Material |
Ferrite |
|
Resonance Frequency |
Fs |
51Hz |
|
DC Resistance |
Rte |
4.6ohm |
|
Mechanical Factor |
Qms |
7.864 |
|
Electrical Factor |
Qes |
0.540 |
|
Total Factor |
Qts |
0.505 |
|
BL Factor |
BL |
20.864T-m |
|
Effective Moving Mass |
Mms |
159.1gr |
|
Equivalent Cas Air Load |
Vas |
163liter |
|
Effective Piston Area |
Sd |
0.13 m |
|
Max. Linear Excursion |
Xmax |
14mm |
|
Vibration velocity |
Cms |
0.06 |
|
Overall Diameter |
461mm |
|
Baffle Cut-out Dia. |
422mm |
|
Bolt Circle Dia. |
442mm |
|
Gasket Thickness |
17mm |
|
Overall Depth |
221mm |
|
Net Weight |
14.8kg |
