Rated Power (1 KHz, THD+N=0.1% |
8Ω stereo 2x500W 4Ω stereo 2x800W 8Ω bridge 1600W |
Frequency Response (1W 8Ω stereo) |
20Hz ̴ 20KHz(±2dB) |
Sensitivity (8Ω stereo @1Khz) |
0.775V/1V/32dB |
Mode |
Stereo/Parallel/Bridge |
Input connectors |
XLR (Neutrik®) |
Output connectors |
Speakon (Neutrik®) & binding post |
Filter Capability |
63V 6800uFx4 |
Input Impedance
|
Balanced 20K Unbalanced 10K |
Channel separation |
≥70dB |
Slew Rate |
≥15V/µs |
S/N ratio |
≥95dB |
Damping Factor |
≥250 |
Output Circuitry |
Class H |
Dimension (W x H x D) |
600x550x200 mm |
Gross Weight |
17.3Kg |
