- FIT 4X800: 800Wx4 @ 4ohms; 1600Wx2 @ 8ohms(Bridged)
- 1U height 9" width of the standard cabinet, compact size, lightweight and portable.
- Class D power amplifier module provides 92% high working efficiency and outputs high power density. Regulated-Switch Mode Power Supply(R-SMPS) ensures constant power output at all times.
- The Active Power Factor Correction (PFC) ensures the amps can work in working voltage ranges from 90V to 260V. Precision Power, Signal, CLIP, and PROT to monitor performance
- Independent limiters per channel offer reliable protection against overload and distortion.
- Independent DC and thermal protection on each channel automatically protect the amplifier and speaker without shutting down the show.
- Comprehensive protection scheme including current, voltage, DC, temperature, short circuit, and open load warnings
- “Front to rear” ventilation system avoids uncomfortable feelings when operating the amps from the front panel. High-quality electronic elements and extraordinarily robust construction ensure long lifespan.
- An efficient cooling system dissipates more heat for extended peak output
- Designed by AERONS INDIA, India.
Rated Power (1 KHz, THD+N=0.1%)
|
8Ω stereo |
4x500W |
4Ω stereo |
4x800W |
|
8Ω bridge |
2X1600W |
|
Frequency Response (1W 8Ω stereo) |
20Hz ̴ 20KHz(±0.5dB) |
|
Sensitivity (8Ω stereo @1Khz) |
0.775V/1V/32dB |
|
Protection |
DC Protection, Short circuit protection, High-temperature protection, Output overload protection, Soft start protection, Clip limit protection, VHF protection, and Progressive volume protection. |
|
Mode |
Stereo/Parallel/Bridge |
|
Fan Speed Regulation |
Auto-speed |
|
Connectors (Each channel) |
Input connectors |
XLR (Neutrik®) |
Output connectors |
Speakon (Neutrik®) |
|
Filter Capability |
1500µF/100Vx4 |
|
Input Impedance |
Balanced |
20K |
Unbalanced |
10K |
|
Channel separation (8Ω load, 1KHz and below) |
≥70dB |
|
Slew Rate |
20V/µs |
|
S/N ratio (8Ω, Rated Power 8Ω) |
≥106dB |
|
Damping Factor (1KHz, 8Ω) |
≥600 |
|
Working Voltage |
PFC, 90˜265V |
|
Output Circuitry |
Class D |
|
Dimension (W x H x D) |
483x44x251 mm |
|
Gross Weight |
4.8Kg |
