HDLA 206
ULTRA COMPACT DUAL LINE ARRAY

  • Dual 6-inch Ultra Compact line array system
  • 2x6” (150mm)/1.5” voice coil LF driver
  • 1x1” (25mm)/ 1.7” voice coil HF driver
  • RATED POWER: 320W
  • PEAK POWER: 1280W
  • IMPEDANCE: 16 ohms
  • SENSITIVITY: 96dB 1watt/1Metre
  • MAXIMUM SPL: 124dB
  • FREQUENCY RESPONSE: 90Hz- 18kHz



                        WHATSAPP CATALOG AND PRICE

HDLA 206

Introducing our Dual 6-Inch Ultra Compact Line Array HDLA206 with 320-Watt Power , housed in a sturdy multilayered plywood enclosure. This exceptional line array system is designed to deliver high-quality sound reproduction in a compact form factor, making it ideal for venues where space is limited but uncompromising audio performance is desired. At the heart of this line array system are two 6-inch drivers, engineered to produce clear, detailed audio across a wide frequency range. Despite
their compact size, these drivers are capable of delivering powerful and dynamic sound, ensuring an immersive listening experience for both small and mid-sized venues.


With a total power output of 320 watts, this line array system has ample headroom to ll the space with rich and balanced sound. Whether you'resetting up for a live performance, conference, or DJ event, this system can handle the demands of various applications with ease.The multilayered plywood enclosure offers superior durability and acoustic performance. The carefully selected plywood materials and construction techniques result in a rigid and resonance-free cabinet, minimizing unwanted vibrations and enhancing sound clarity. This ensures that the audio output remains pristine and free from distortion, even at high volume levels. To further enhance the reliability and aesthetics of the system, the line array comes with aluminum accessories. These components not only provide structural integrity but also add a touch of sleek elegance to the overall design.


In summary, our Dual 6-Inch Ultra Compact Line Array with 320-Watt Power and Aluminum Accessories is a versatile and high-performance audio solution. Its compact size, powerful output, multilayered plywood enclosure, and aluminum accessories make it an excellent choice for venues where space is limited, without compromising on audio quality or durability. Experience pristine sound reproduction and impressive coverage with this exceptional line array system

HDLA 206

                         Technical Specifications

Design

 Dual 6” Ultra compact Line Array

Components

2X6” (150mm)/1.5” voice coil LF driver

1x1” (25mm)/ 1.7” voice coil HF driver

Power (RMS)

320W

Max Power

1280W

Sensitivity

96dB 1watt/1Metre

Impedance

16 ohms

Max SPL

124dB

Frequency Response

LF: 90Hz- 18kHz

Connector

2x 4-pole SpeakON

Crossover

1.1kHz Passive

Dispersion (-6dB)

Horizontal Coverage: 100°

Vertical Coverage: varies, Depending on array length

and configuration

Dimensions

(W)430mmX(D)202mmX(H)372mm

Weight

12 KGS
