PRO7.0 offers 700 watts at 8Ω stereo. Each channel works at 2Ω to satisfy all requirements.
PRO7.0 adopts Audiocenter's latest Class H+ circuitry to eliminate the Class H cross-switching distortion.
PRO7.0 has a very clear and clean sound and a high damping factor. This makes PRO7.0 suitable for any kind of application, from high-power loudspeakers to critical monitoring where very high requirements are mandatory. It can be widely used in fixed installations and touring performances such as bars, nightclubs, multi-functional halls, museums, religious venues, commerce sites, lecture halls, wedding ceremonies, etc.
|
Rated Power(20Hz-20KHz, <0.1%THD) |
2×700W@8Ω stereo 2×1100W@4Ω stereo 2×1400W@2Ω stereo 2200W@8Ω bridge 2800W@4Ω bridge |
|
A-Guard Protection System |
DC protection /Short circuit protection /Smart overheat management /Overheat protection /Input overload protection /Output overload protection /Soft startup protection / Limiter protection Up to 9V |
|
Frequency Response(1W 8Ω stereo) |
20Hz-20KHz(±0.5dB) |
|
Sensitivity |
0.775V / 36dB /32dB |
|
Input Connectors Output Connectors |
male XLR & female XLR 3×Speaker connector |
|
Filter Capacitor Capacity |
12000μf / 80V×8 |
|
Input Impedance |
Balanced 20KΩ/ Unbalanced 10KΩ |
|
Crosstalk(20Hz-20KHz, Rated power 8Ω) |
≥65dB |
|
S/N Ratio(Rated power 8Ω, A weighted) |
≥108dB |
|
Damping Factor(1KHz＆8Ω) |
≥500 |
|
Intermodulation Distortion(20Hz-20KHz, half power) |
≤0.05% |
|
Total Harmonic Distortion(20Hz-20KHz, Rated power 8Ω) |
≤0.05% |
|
Phase Response(1W＆8Ω, 20Hz-20KHz) |
20Hz+4° 20KHz-12° |
|
Slew Rate |
≥45V/μs |
|
Output Circuitry |
Class H+ |
|
Power Consumption(Dual channel driven 4Ω, 1/8RMS/230V) |
3.4A |
|
Rack Space |
2U |
|
Cooling |
Back to front venting, mandatory cooling |
|
Dimension(W×H×D) |
483×88×456mm |
|
Net Weight |
22.5Kg |
