Nominal Diameter |
8inch |
|
Nominal Impedance |
16ohm |
|
Minimum Impedance |
11ohm |
|
Nominal Power Handling |
200Watts |
|
Continuous Power Handling |
400Watts |
|
Sensitivity |
96.1dB |
|
Frequency Range |
60-1.8KHz |
|
Voice-coil Diameter |
51.5mm |
|
Voice-coil Material |
CCAW |
|
Kind of layer |
out 2layers |
|
Magnet Diameter |
156*20mm |
|
Magnet Material |
Ferrite |
|
Resonance Frequency |
Fs |
70Hz |
|
DC Resistance |
Rte |
11ohm |
|
Mechanical Factor |
Qms |
10.006 |
|
Electrical Factor |
Qes |
0.359 |
|
Total Factor |
Qts |
0.347 |
|
BL Factor |
BL |
15.740T-m |
|
Effective Moving Mass |
Mms |
18.2gr |
|
Equivalent Cas Air Load |
Vas |
26.28liter |
|
Effective Piston Area |
Sd |
0.02 m |
|
Max. Linear Excursion |
Xmax |
7mm |
|
Vibration velocity |
Cms |
0.27 |
|
Overall Diameter |
212mm |
|
Baffle Cut-out Dia. |
187mm |
|
Bolt Circle Dia. |
197mm |
|
Gasket Thickness |
9mm |
|
Overall Depth |
103mm |
|
Net Weight |
4.1kg |
