Rated Power (1 KHz, THD+N=0.1%) |
8Ω stereo 1050W |
|
4Ω stereo 1550W |
|
2Ω stereo 2200W |
|
8Ω bridge 3100W |
|
4Ω bridge 4400W |
Frequency Response (1W 8Ω stereo) |
20Hz ̴ 20KHz |
Mode |
Stereo/Bridge/Parallel |
Input connectors |
Jack & female XLR (Neutrik®) |
Output connectors |
Binding post & Speakon (Neutrik®) |
Input Impedance |
Balanced 20K Unbalanced 10K |
Input Sensitivity |
1.25V |
Filter Capability |
15000µf/ 50V |
Total Harmonic Distortion (20Hz~20KHz Rated Power, 8Ω) |
≤0.02%
|
S/N ratio (8Ω, Rated Power 8Ω) |
≥100dB |
Damping Factor (1KHz, 89) |
≥250 |
Dimension (W x H x D) |
482x132x404 mm |
Net Weight |
30.8Kg |
Gross Weight |
34.9Kg |
