GENERAL SPECIFICATIONS
|
Nominal Diameter |
15inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.1ohm |
|
Nominal Power Handling |
500Watts |
|
Continuous Power Handling |
1000Watts |
|
Sensitivity |
98.0db |
|
Frequency Range |
40-3.0KHZ |
|
Effective Diaphragm diameter |
332mm |
|
Voice-coil Diameter |
76.2mm |
|
Voice-coil Material |
CCAW |
|
Voice-coil Winding Depth |
20mm |
|
Number of layers |
2 |
|
Kind of layer |
in/out |
|
Magnet Diameter |
190*25mm |
|
Top Plate Thickness |
11 |
THIELE-SMALL PARAMETERS
|
Resonance Frequency |
Fs |
40Hz |
|
DC Resistance |
Rte |
5.1 ohm |
|
Mechanical Factor |
Qms |
9.01 |
|
Electrical Factor |
Qes |
0.46 |
|
Total Factor |
Qts |
0.438 |
|
BL Factor |
BL |
17.9 T-m |
|
Effective Moving Mass |
Mms |
107.5 gr |
|
Equivalent Cas Air Load |
Vas |
135.2 liters |
|
Effective Piston Area |
Sd. |
0.865 m2 |
|
Max. Linear Excursion |
Xmax |
7.25 mm |
|
Half-Space Efficiency |
Eff |
2.25% |
MOUNTING INFORMATION
|
Overall Diameter |
393mm |
|
Mount Buffer cut-out Diameter |
356mm |
|
Bolt Circle Diameter |
375mm |
|
Bolt Hole Diameter |
7mm |
|
Overall Depth |
177mm |
|
Not Weight |
8.05kg |
