Nominal Diameter |
15inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.5ohm |
|
Nominal Power Handling |
650Watts |
|
Continuous Power Handling |
1300Watts |
|
Sensitivity |
97dB |
|
Frequency Range |
50-2.5KHz |
|
Voice-coil Diameter |
87mm |
|
Voice-coil Material |
CCAW |
|
Kind of layer |
In/out |
|
Top Plate Thickness |
10 |
|
Magnet Diameter |
200*25mm |
|
Magnet Material |
Ferrite |
|
Resonance Frequency |
Fs |
50Hz |
|
DC Resistance |
Rte |
5.6ohm |
|
Mechanical Factor |
Qms |
11.79 |
|
Electrical Factor |
Qes |
0.598 |
|
Total Factor |
Qts |
0.569 |
|
BL Factor |
BL |
18.88T-m |
|
Effective Moving Mass |
Mms |
111.879gr |
|
Equivalent Cas Air Load |
Vas |
78.06liter |
|
Effective Piston Area |
Sd |
876 cm |
|
Max. Linear Excursion |
Xmax |
7mm |
|
Half Space Efficiency |
Eff |
2.06% |
|
Overall Diameter |
393mm |
|
Baffle Cut-out Dia. |
353mm |
|
Bolt Circle Dia. |
379mm |
|
Gasket Thickness |
12mm |
|
Overall Depth |
170mm |
|
Net Weight |
9.1kg |
