GENERAL SPECIFICATIONS
|
Nominal Diameter |
15inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.2ohm |
|
Nominal Power Handling |
600Watts |
|
Continuous Power Handling |
1200Watts |
|
Sensitivity |
98.0dB |
|
Frequency Range |
40-4KHz |
|
Voice-coil Diameter |
86mm |
|
Voice-coil Material |
CCAW |
|
Kind of layer |
out 2layers |
|
Magnet Diameter |
200mm |
|
Magnet Material |
Ferrite |
THIELE-SMALL PARAMETERS
|
Resonance Frequency |
Fs |
42Hz |
|
DC Resistance |
Rte |
5.2ohm |
|
Mechanical Factor |
Qms |
6.842 |
|
Electrical Factor |
Qes |
0.381 |
|
Total Factor |
Qts |
0.361 |
|
BL Factor |
BL |
18.057T-m |
|
Effective Moving Mass |
Mms |
90.7gr |
|
Equivalent Cas Air Load |
Vas |
204.56liter |
|
Effective Piston Area |
Sd |
0.09 m |
|
Max. Linear Excursion |
Xmax |
8mm |
|
Vibration velocity |
Cms |
0.15 |
MOUNTING & SHIPPING INFORMATION
|
Overall Diameter |
391mm |
|
Baffle Cut-out Dia. |
360mm |
|
Bolt Circle Dia. |
373mm |
|
Gasket Thickness |
17mm |
|
Overall Depth |
181mm |
|
Net Weight |
9.6kg |
