LA3032 V2
2-WAY LINE ARRAY
NEODYMIUM

  • 1X12”(300mm)/3.5” voice coil Neo LF driver
  • 3x1” (25mm)/1.4” voice coil Neo HF driver
  • RATED POWER: 750W
  • PEAK POWER: 1500W
  • SENSITIVITY: 99Db 1watt/1Metre
  • MAXIMUM SPL: 129dB
  • FREQUENCY RESPONSE: 50Hz- 20kHz ±3dB







                    WHATSAPP CATALOG AND PRICE

LA3032 V2

LA3032 v2 is a line array loudspeaker for large-scale sound reinforcement. Using the LA3032 v2 flying frame it can be flown in vertical columns with up to 3 cabinets giving a 100° constant dispersion pattern in the horizontal plane.LA3032 v2 is a 2-way design housing 1×12"LF drivers and 3 ×1" exit neodymium driver with a plastic wave guideline array horn.
FEATURES
- High-quality plywood with wear-resistant and waterproof polyurea paint
- Exceptional sound quality, powerful response & long throw.
- Neodymium HF unit and Neodymium woofer
- High-grade & durable cabinet design.
- True 100°(-6dB) horizontal mid and HF pattern control.
- High power- maximum SPL 123dB continuous, 129dB Peak.
- High-quality passive crossover network for maximum reliability.
- Extra textured anti-scratch paint finish.
- Convenient for hanging and stacking
- Top hat fitting for tripod
- Easy carry handles & heavy-duty protective grille.

LA3032 V2

FREQUENCY RESPONSE

50Hz- 20kHz ±3dB

DRIVERS

1X12” (300mm)/3.5” voice coil Neodymium LF driver



3x1” (25mm)/1.4” voice coil Neodymium HF driver

RATED POWER

750W

PEAK POWER

1500W

SENSITIVITY

99Db 1watt/1Metre

SPL

123dB

MAXIMUM SPL

129dB

IMPEDANCE

8Ω

DISPERSION (-6dB)

100 X 15°

CROSSOVER

2kHz Passive

CONNECTORS

2XSpeakON NL4

DIMENSIONS

(W)597mmX(D)372mmX(H)342mm

WEIGHT

22KG
